5E Series Utility Tractors | 5067E

Utility Tractors
John Deere
#5067elv

Disclaimer |

Characteristics

  • 67.5 hp (50.4 kW) 3-cylinder diesel engine
  • 2WD or MFWD
  • eHydro™ transmission option with Twin Touch™ foot pedals
  • Open operator station, standard HVAC cab, or premium cab

Note that this product is available in store only.
Get pre-approved for financing

Description

Handle heavier-duty chores around the farm, property or roadside with the 5067E utility tractor.

Specifications

Engine description John Deere PowerTech™ 3029 EWR
Engine displacement 3 cylinders: 2.9 L
179 cu in.
Rated engine power At 2100 rpm: 50.4 kW
67 hp
Maximum engine power 50.4 kW
67.6 hp
Rated PTO power (hp SAE) At 2100 rpm: OOS 39.6 kW (53 hp)
Cab 36.6 kW (49 hp)
Transmission type Standard: SyncShuttle 9F/3F;
Optional: PowrReverser 12F/12R; Optional: eHydro™
Hydraulic pump rated output 68.8 L/min
18.2 gpm
Rear hitch category (SAE designation) Category 2; convertible to 1
Engine Make John Deere
Engine Model John Deere PowerTech™ 3029 EWR
Engine Family NJDXL02.9339
Displacement (L) 3 cylinders: 2.9 L
Displacement (cu in.) 3 cylinders: 179 cu in.
Rated Engine Power (hp) 67.5 hp
@2100 rpm
Rated Engine Power (kw) 50.4 kW
@2100 rpm
Pump Rated Output 18.2 gpm
(68.6 L/min) - PR/TSS (2 Pumps Engine Mouted)
29.6 gpm
(112 L/min) - HST (3 Pumpes (2 Engine moutned and 1 Drive Train Mounted)
Base Machine Weight (lb) 2WD OOS: 5,445 lb
2WD Cab: 6,480 lb
MFWD OOS: 5,919 lb
MFWD Cab: 6,702 lb
Base Machine Weight (kg) 2WD OOS: 2,470 kg
2WD Cab: 2,939 kg
MFWD OOS: 2,685 kg
MFWD Cab: 3,040 kg
Description John Deere PowerTech™ 3029 EWR
Engine type 3029HPY110
Engine family NJDXL02.9339
Rated speed 2100 rpm
Aspiration Turbocharged
Cylinders liners Wet sleeved
Emission level Final Tier 4
After treatment type DOC/EGR
Displacement 3 cylinders: 2.9 L
179 cu in.
Rated power At 2100 rpm: 50.4 kW
67 hp
Rated PTO power (hp SAE) At 2100 rpm: OOS 39.6 kW (53 PTO hp)
Cab 36.6 kW (49 PTO hp)
Power boost 0 percent
Maximum engine power 50.4 kW
67.6 hp
Engine peak torque At 1500 rpm: 280 Nm
206 lb-ft
PTO torque rise 21 percent
Type Standard: SyncShuttle™ 9F/3R
Optional: PowrReverser™ 12F/12R
Clutch; wet/dry SyncShuttle™: Dry
PowrReverser™: Wet
Creeper KIT AVAILABLE
Transmission Type Standard: SyncShuttle 9F/3F;
Optional: PowrReverser 12F/12R;
Optional: eHydro™
Clutch SyncShuttle™: Dry
PowrReverser™: Wet
Type Open center
Pump rated output 68.8 L/min
18.2 gpm
Available flow at a single rear SCV 43.1 L/min
11.4 gpm
Number of rear selective control valves (SCVs) Standard: One
Optional: Two
Number of mid selective control valves (SCVs) Standard: Zero
Optional: Up to Three
Joystick SCV control Mechanical
Hitch draft control load sense type Mechanical
Remote control valves available Standard: One
Optional: Two
Hitch category (SAE designation) Category 2; convertible to 1
Maximum lift capacity behind lift points 1448 kg
3192 lb
Sensing type Top link
Rear Hitch Category (SAE Designation) Category 2; convertible to 1
Maximum Lift Capacity at 610-mm Behind Hitch Point 3,192 lb
(1,448 kg)
Draft Control Sensing Mechanical
Drawbar category BASIC DRAWBAR
Maximum vertical load Road/field use (short position): 1120 kg
2470 lb
Field use (fully extended): 760 kg
1675 lb
Type SyncShuttle™: Independent 540
PowrReverser™: Independent 540/540E
Engine rpm (at rated PTO speeds) 540 at 2100 rpm
540E at 1588 rpm
Economy PTO speeds 540/540E
PTO actuation SyncShuttle™: Mechanical (lever)
PowrReverser™: Electrohydraulic
Engine rpm at rated PTO speeds (540/1.000) 2100
Engine rpm at rated PTO speeds (540/540E/1.000) 540 @ 2,100 rpm
540E @ 1,588 rpm
PTO Category SyncShuttle™ : Independent 540
PowrReverser™/eHydro™ : Independent 540/540E
Rated PTO Power (hp) OOS (PR/TSS): 55.3 hp
@2100 rpm
CAB (PR/TSS): 53.3 hp
HST: 44.5 hp
Rated PTO Power (kW) OOS (PR/TSS): 41.2 kW
@2100 rpm
CAB (PR/TSS): 39.7 kW
HST: 33.2 kW
Engagement Method SyncShuttle™: Mechanical (lever)
PowrReverser™: Electrohydraulic
Type Flange
Final drive type Planetary
Differential controls Mechanical (pedal)
Brakes, type and control Hydraulic wet disc
Rear differential lock Yes
Rear Axle Type Flange
Differential Control Mechanical (pedal)
Final Drive Planetary
Type Standard: Two-Wheel Drive (2WD)
Optional: Mechanical Front Wheel Drive (MFWD)
Front Axle Type Standard: Two-Wheel Drive (2WD)
Optional: Mechanical Front Wheel Drive (MFWD)
Rear 2WD: 16.9-28 R1 Bias
MFWD: 16.9-28 R1 Bias
Turning radius with brakes 2WD: 3.1 m
10.2 ft
MFWD: 3.94 m
12.9 ft
Turning radius without brakes 2WD: 3.5 m
11.5 ft
MFWD: 4.65 m
15.3 ft
Front Tires Size FRONT 11L-15 in. 8PR F2-M Bias / REAR 14.9-28 In. 6PR R1 Bias
Alternator size OOS: 70 amp
Cab: 110 amp
Battery options 12 V
Working lights LED
Type of bulb in headlight (Halogen, Zenon, LED) OOS: Halogen
Cab: LED
Type of bulb in beacon (Halogen, Zenon, LED) Kit: Halogen
Battery Voltage (V) 12 V
Battery Capacity 800 CCA** with 145 Minute Reserve Capacity
Alternator Capacity Open Station - 60 Amp Alternator
Cab - 110 Amp Alternator
Driving Lights LED
Rollover protective structure, OOS Rigid - foldable - telescopic
Foldable, two-post
Platform - flat/straddle
Straddle
Gearshift location - console/floor
Floor, on the side
Seat Standard: Mechanical
Premium Cab: Air Ride
Instructional seat KIT AVAILABLE
Display Simple automotive-style instrument cluster
Radio BLUETOOTH OPTIONAL
dB(A) rating 81 dBA
ROPS Type Rollover protective structure, OOS
Gearshift Location LEVER ON FLOOR
Seat Suspension STANDARD: MECHANICAL
OPTIONAL: AIR SUSPENSION; AIR
SUSPENSION WITH SWIVEL
Degree of Seat Swivel, Left Hand (degree (angle)) 7 degree (angle)
Degree of Seat Swivel, Right Hand (degree (angle)) 15 degree (angle)
Primary Display NGPD
Wheelbase 2WD and MFWD: 2050 mm
80.7 in.
Overall length 3639 mm
143.3 in.
Approximate shipping weight, Open;Cab 2WD OOS: 2520 kg
5555 lb
2WD Cab: 2989 kg
6590 lb
MFWD OOS: 2735 kg
6029 lb
MFWD Cab: 3090 kg
6812 lb
Fuel tank OOS: 72.5 L
19 U.S. gal.
Cab: 82 L
21 U.S. gal.
Diesel exhaust fluid (DEF) tank Not Applicable
Fuel Tank Capacity (gal.) OOS: 19 U.S. gal.
Cab: 21 U.S. gal.
Fuel Tank Capacity (L) OOS:72.5 L
Cab: 82 L
AutoTrac ready No
ISOBUS ready No
Country of manufacture Sub assembly in Pune, India, Final assembly in Augusta, GA
Date collected 5/8/2026
Country of Manufacture INDIA
Wheel or Track Configuration wheel
Drive Type Planetary
Engine Make John Deere
Engine Model John Deere PowerTech™ 3029 EWR
Engine Family NJDXL02.9339
Emissions Certifications Final Tier 4
Displacement (L) 3 cylinders: 2.9 L
Displacement (cu in.) 3 cylinders: 179 cu in.
Aspiration Turbocharged
Number of Cylinders 3 cylinders
Cylinder Liners Wet sleeved
Aftertreatment Type DOC/EGR
Rated Engine Speed (rpm) 2100
Rated Engine Power (hp) 67.5 hp
@2100 rpm
Rated Engine Power (kW) 50.4 kW
@2100 rpm
Fuel Type Diesel
Torque Rise (%) 22%
Hydraulic System Type OPEN CENTER
Pump Rated Output 18.2 gpm
(68.6 L/min) - PR/TSS (2 Pumps Engine Mouted)
29.6 gpm
(112 L/min) - HST (3 Pumpes (2 Engine mounted and 1 Drive Train Mounted)
Number of Rear Selective Control Valves (SCVs) Standard: one;
Optional: two
Available Flow at a Single Rear SCV 43.1 L/min
11.4 gpm
Hydraulics Number of Mid Selective Control Valves (SCVs) Standard: zero;
Optional up to three
SCV Control Mechanical
Steering Type TSS: Fixed; PR/eHydro™ : Tilt or Tilt/Telescoping
Primary Brakes Hydraulic wet disc
Parking Brake park pawl brake
Connectivity JD LINK™ Modem
Wheelbase (in.) 80.7 in.
Wheelbase (mm) 2,050 mm
Base Machine Weight (lb) 2WD OOS: 5,445 lb
2WD Cab: 6,480 lb
MFWD OOS: 5,919 lb
MFWD Cab: 6,702 lb
Base Machine Weight (kg) 2WD OOS: 2,470 kg
2WD Cab: 2,939 kg
MFWD OOS: 2,685 kg
MFWD Cab: 3,040 kg
Overall Length (in.) 144.5 in.
Overall Length (mm) 3,670 mm
