Description
At 13.7 m (45 ft) wide, the CF27 20 Corn Head is built for 508-mm (20‑inch) corn for X9 Combines.
Home / Equipment / Agriculture / Harvest / Combines and accessories / Corn Heads / CF27 20 Corn Head
At 13.7 m (45 ft) wide, the CF27 20 Corn Head is built for 508-mm (20‑inch) corn for X9 Combines.
| Approximate overall width |
With 50.8-cm (20-in.) row spacing: 14.2 m 46.4 ft |
| Approximate folded width |
With 50.8-cm (20-in.) row spacing: 8.6 m 28.1 ft |
| Row spacings |
50.8 cm 20 in. |
| Deck plate adjustment | Hydraulic adjustment |
| Gathering chain adjustment | Spring loaded, self-adjusting |
| Gathering chains | Heavy-duty, 620, endless steel roller chain with chromed pins (no master connecting link) |
| Gathering points | Four-position, low-profile floating type hinged above gathering chains |
| Center and outer gatherings | Hinged, quickly removable |
| Gathering chains | Heavy-duty, 620, endless steel roller chain with chromed pins (no master connecting link) |
| Minimum clearance between gathering chains and ground |
32 mm 1.25 in. |
| Row unit drive | Enclosed, submerged-in-lubricant gearbox, driven by single input hexagon shaft |
| Gathering chain adjustment | Spring loaded, self-adjusting |
| Stalk rolls | Opposed, intermeshing, and chopping (two per row-unit) |
| Deck plate adjustment | Hydraulic adjustment |
| Slip clutch | One per row-unit plus auger drive |
| Trash knives | Full-length, one-piece, heat-treated steel |
| Stalk deflectors | Factory-installed option |
| Approximate overall width |
With 50.8-cm (20-in.) row spacing: 14.2 m 46.4 ft |
| Approximate folded width |
Points in operating position (lowered) 2.9 m 9.67 ft Points folded up (service position) 2.3 m 7.5 ft With 50.8-cm (20-in.) row spacing: 8.6 m 28.1 ft |
| Approximate shipping weight (includes shipping skid) |
With 50.8-cm (20-in.) row spacing: non StalkMaster™ 7,887 kg 17,388 lb |
| Row spacings |
50.8 cm 20 in. |
| Standard weight |
With 50.8-cm (20-in.) row spacing: non StalkMaster 7,706 kg 16,991 lb With 50.8- cm (20 in) row spacing and 15 rows of Stalk Deflectors: 7,940 kg 17,504 lb |
| Date collected | 28 January 2026 |
